4500mm Glassine Paper Production Line for Release Liner & Packaging
Glassine paper is one of the more demanding grades to run on a paper machine. It asks a lot from the forming section, the press and especially the drying and calendering stages — and small deviations show up immediately as grease resistance problems or uneven finish. Our glassine paper production line is built around this reality, with each section tuned to hold tight tolerances over long production runs.
Technical Data of the Glassine Paper Production Line
Paper type: Glassine paper, supercalendered greaseproof paper
Raw material: 100% bleached softwood/hardwood pulp
Capacity: 120-180t/d
Basis weight: 30-80g/㎡
Net paper width: 4500mm
Working speed: 600m/min
Design speed: 700m/min
Driving type: AC frequency conversion sectional drive
From stock preparation to the winder, the line is configured for clean, stable operation: high-efficiency refining for uniform fiber development, a well-sealed press section that protects sheet integrity at light weights, and a precisely controlled drying curve to avoid curl and blistering before calendering. The result is glassine with the smoothness, transparency and grease barrier performance that converters expect.
If you are planning a glassine paper project — whether for release liner base, food wrapping or premium label stock — send us your raw material and target specification. We will work out a line configuration and quotation for you. Email address:paperproductmachine@gmail.com
